Mini-ITX SFF Case — 15L · PCIe 5.0
MESHROOM S V2
The next evolution of the award-winning Meshroom S. Now with a PCIe 5.0 riser cable, redesigned front power button, and support for 360mm radiators — all in the same compact 15L footprint.
15L
Volume
325mm
Max GPU
360mm
Radiator
PCIe 5.0
Riser Cable
Available Colors
What's New in V2: PCIe 5.0 riser cable included, front power button relocated for easier access, improved build quality and panel fit.
Overview
AWARD-WINNING SFF,
NOW FUTURE-PROOF
The Meshroom S V2 builds on the success of the original Meshroom S, adding PCIe 5.0 support, a more accessible front power button, and refined build quality — while keeping the same compact 15L footprint that made it a community favorite.
With support for 360mm radiators, 3-slot GPUs up to 325mm, and SFX/SFX-L power supplies, the Meshroom S V2 delivers exceptional performance in a form factor that fits anywhere.
15.07 L
Volume
325mm
Max GPU Length
360mm
Max Radiator
PCIe 5.0
Riser Cable
Key Features
What's New & What's Great
V2 Upgrades
What's New in V2
PCIe 5.0 Riser Cable
Included PCIe 5.0 riser cable provides full bandwidth for the latest GPUs, with backward compatibility for PCIe 4.0 and 3.0.
Front Power Button
Relocated power button to the front panel for easier access during builds and daily use.
Improved Build Quality
Enhanced panel fit, tighter tolerances, and refined finishing for a more premium feel.
360mm Radiator in a 15L Case
The Meshroom S V2 supports a 360mm radiator in the top position — an extraordinary feat for a 15L Mini-ITX case. Pair it with a high-performance AIO for cooling that rivals full-size ATX builds.
3-Slot GPU Support — Up to 325mm
Accommodates GPUs up to 325mm in length and 3-slot (140mm) or 3.4-slot (136mm) thickness. This covers virtually all current high-end graphics cards including the RTX 4090 and RX 7900 XTX.
SFX / SFX-L PSU Optimized
Designed around compact SFX and SFX-L power supplies to maximize internal space. The optimized PSU placement leaves more room for cable management and larger radiators.
Full Mesh Panels — Maximum Airflow
All-around fine mesh panels ensure excellent airflow across all components. The tool-free push-pin panel design makes cleaning and maintenance quick and easy.
Technical Specs
Full Specifications
Dimensions & Weight
Expansion & Storage
Front I/O
Cooling Support
Materials & General
Compatibility
Quick Compatibility Check
Key compatibility constraints at a glance.
Motherboard
Mini-ITX / Mini-DTX
PSU Type
SFX / SFX-L (recommended); ATX (with adapter)
CPU Cooler Height
Up to 75mm (with top radiator); up to 95mm (without)
GPU Max Length
325mm × 140mm (3-slot); 325mm × 136mm (3.4-slot)
Top Radiator
Up to 360mm radiator + fans
Side Radiator
Up to 240mm radiator + fans
